Creativity is at the heart of every dream. Every idea, every groundbreaking leap that changes our world starts with the vision of talented creators. At DJI, we give these creators the tools they need to bring their ideas to life.
Our platforms empower them to capture images that were once out of reach. Our flying and camera stabilization systems redefine camera placement and motion. Amazing photos and video, treasured personal memories, and high-end professional imagery are captured every day, in every corner of the world using DJI products.

We do this through an unparalleled commitment to R&D, a culture of constant innovation and curiosity, and a focus on transforming complex technology into easy-to-use devices. Building on the ethos of “form follows function,“ our products combine advanced technology with dynamic designs.

DJI DOCK 2

Taking autonomous flight to the next level with DJI Dock 2

The DJI Dock 2 represents a significant leap forward in autonomous drone technology, building upon the foundation laid by its predecessor, DJI Dock 1. Designed for efficiency, versatility, and ease of use, Dock 2 is tailored for a broad spectrum of applications, from surveying and mapping to security and emergency response. This comprehensive product description highlights the major updates, compatible aircraft, software support, application scenarios, and technical specifications.

Major updates from DJI Dock 1 to DJI Dock 2

Reduced size and weight: Dock 2 boasts a smaller footprint and lighter weight at just 34kg and covering only 0.34m^2, making it significantly easier to transport and deploy than its predecessor.

Enhanced performance: With a maximum flight time of 50 minutes and an operational range of 10 km, the device improves both coverage and efficiency over Dock 1.

Surveying capability: Integration of a 20MP surveying camera (identical to the M3E camera) with the M3D variant opens new avenues in construction site management, mining, and more, thanks to its high-precision surveying and mapping capabilities.

Cost-effectiveness: It is designed to be more affordable in terms of both hardware and deployment/maintenance services.

Compatible aircraft

DJI Dock 2 is compatible with two specific aircraft variants: the DJI Matrice 3 dock version (M3D) and the DJI Matrice 3 thermal dock version (M3TD), each equipped with distinct camera setups for specialized tasks.

The M3D is optimized for high-precision surveying and mapping, while the M3TD is suited for public safety operations and inspections.

Software and SDK/API support

It works seamlessly with the DJI FlightHub 2 platform and continues to support Cloud API for integration with third-party cloud platforms. The E-Port on M3D/M3TD aircraft allows for the mounting of third-party payloads, enhancing the system's flexibility and application potential.

Application scenarios

The 20MP wide camera on the M3D, similar to the M3E camera, enables high-precision surveying and mapping, making Dock 2 ideal for construction site progress monitoring, earthwork measurements, and disaster monitoring.

The M3TD's combination of thermal and RGB cameras allows for applications in security patrol, emergency response, and automated asset inspections.

Technical specifications and improvements

DJI Dock 2 features a significant reduction in size and weight compared to Dock 1, alongside improvements in operational efficiency and environmental adaptability.

With a max takeoff altitude of 2500m, an operational radius of 10km, and a charging time of 32 minutes for a battery from 20% to 90%, it is designed for robust performance.

Additionally, it supports smart oblique photography, enhancing its utility in detailed mapping and surveying tasks.

Why consider the DJI Dock 2?

The DJI Dock 2 embodies the cutting-edge of autonomous drone technology, offering unparalleled efficiency, flexibility, and capability in a compact and cost-effective package.

Whether for construction monitoring, disaster management, or security operations, it provides a reliable, high-performance solution for a wide range of applications. With its advanced features and improved specifications, DJI Dock 2 is set to redefine the standards for autonomous drone operations.

The Mavic 3 Enterprise Series redefines industry standards for small commercial drones. With a mechanical shutter, a 56× zoom camera, and an RTK module for centimeter-level precision, the Mavic 3E brings mapping and mission efficiency to new heights. A thermal version is available for firefighting, search and rescue, inspection, and night operations.

Compact & Portable
56× Hybrid Zoom
640 × 512 PX Thermal Camera (M3T)
45-MIN Max Flight Time
DJI O3 Enterprise Transmission
Optional RTK
Optional Loud Speaker

Click to learn more - Mavic 3 Enterprise Series

Survey with Speed

 Mavic 3E's wide-angle 4/3 CMOS, 20MP sensor has a mechanical shutter to prevent motion blur and supports rapid 0.7-second interval shooting. Complete mapping missions with extraordinary efficiency without the need for Ground Control Points.

Focus and Find

Both Mavic 3E and Mavic 3T are equipped with a 12MP Zoom Camera, supporting up to 56× Max Hybrid Zoom to see essential details from afar.

Simultaneous Split-Screen

Zoom Mavic 3T's thermal and zoom cameras support 28× continuous side-by-side zoom for easy comparisons.

Improved Low-Light Performance

Mavic 3E's Wide camera has large 3.3μm pixels that, together with intelligent low-light mode, offer significantly improved performance in dim conditions.

Batteries for Endurance

45-min flight durations let you cover more ground each mission, for surveying of up to 2 square kilometers in a single flight.

 Max Flight Time 45 Minutes

Surveying Area in a Single Flight 2 Square Kilometers

Fast charge batteries with 100W charging hub, or directly charge the drone with 88W fast charging.

Charging Hub 100W Aircraft 88W

Surveying Area in a Single Flight 2 Square Kilometers

Check out the M3T

Matrice 30 Series

The DJI Matrice 30 is DJI Enterprise's flagship drone that can be carried around in a backpack. Multiple high-performance sensors are integrated into a single camera payload, and the entire system is operated by an innovative redesigned remote control. It also runs on improved Pilot 2 software, which dramatically improves the flight experience. The M30 model provides significantly greater power, endurance, and capability for tough professional applications, but its compact size makes it perfect for easy transportation and quick setup. It works seamlessly with the new DJI FlightHub 2 fleet management cloud-based software as well as the DJI Dock for collaboration with remote and unattended operations, delivering efficiency and innovation to a wide range of industry sectors.
The DJI M30 series is available in two different configurations: the M30 and the M30T. Among the features of the M30 model are a 48-megapixel 1/2-inch CMOS sensor zoom camera with 5-16 optical and 200-200 digital zoom, a 12-megapixel wide-angle camera, 8-megapixel photo 4K/30 fps video resolution, and a laser rangefinder that can provide precise coordinates for objects up to 1,200 meters away. The M30T includes an extra radiometric thermal camera with a resolution of 640x512 pixels.

Matrice 300 Series

The Matrice 300 RTK is DJI’s latest commercial drone platform that takes inspiration from modern aviation systems. Offering up to 55 minutes of flight time, advanced AI capabilities, 6 Directional Sensing & Positioning and more, the M300 RTK sets a whole new standard by combining intelligence with high-performance and unrivaled reliability.
