MATRICE 300 RTK NA SP Sheild Basic

MATRICE 300 RTK NA SP Sheild Basic

by DJI
Sold out
$10,559.00

  • The Matrice 300 RTK is DJI's latest commercial drone platform that takes inspiration from modern aviation systems. Offering up to 55 minutes of flight time, advanced AI capabilities, 6 directional sensing & positioning and more, the M300 RTK sets a whole new standard by combining intelligence with high-performance and unrivaled reliability.

    Improved Transmission System

    The all-new OcuSync Enterprise enables transmission up to 15 km away and supports triple-channel3 1080p video. Real-time auto-switching between 2.4 GHz and 5.8 GHz4 enables more reliable flight near high-interference environments, while AES-256 encryption offers secure data transmission.

    15km Transmission Range
    1080p Triple-channel Video
    2.4 /5.8GHz Real-time Auto-switching

    Enhanced Flight Performance

    The refined airframe and propulsion system design gives you a more efficient and stable flight, even in harsh conditions.

    55min Max Flight Time
    7m/s Max Descend Speed
    7000m Service Ceiling
    15m/s Wind Resistance
    23m/s Max Speed

    Multiple Payload Configurations

    Configure your M300 RTK to fit your mission needs. Mount up to 3 payloads simultaneously, with a maximum payload capacity of 2.7 kg.

    Single Downward Gimbal
    Single Upward Gimbal x Single Downward Gimbal
    Single Upward Gimbal x Dual Downward Gimbals

    Live Mission Recording

    Record mission actions such as aircraft movement, gimbal orientation, photo shooting, and zoom level to create sample mission files for future automated inspections.

    AI Spot-Check

    Automate routine inspections and capture consistent results every time. Onboard AI recognizes the subject of interest and identifies it in subsequent automated missions to ensure consistent framing.

    Waypoints 2.0

    Create up to 65,535 waypoints and set multiple actions for one or more payloads, including 3rd party ones, at each waypoint. Flightpath planning is also optimized to maximize flexibility and efficiency for your missions.

    PinPoint

    Mark an object in camera or map view with a quick tap, and advanced sensor fusion algorithms will immediately calculate its coordinates, which are projected to all camera views as an AR icon. The location of the subject is automatically shared with another remote controller, or to online platforms such as DJI FlightHub

    Smart Pin & Track8

    PinPoint

    Mark an object in camera or map view with a quick tap, and advanced sensor fusion algorithms will immediately calculate its coordinates, which are projected to all camera views as an AR icon. The location of the subject is automatically shared with another remote controller, or to online platforms such as DJI FlightHub9.

    Smart Track

    Identify and follow moving subjects like people, vehicles, and boats with the Smart Track function, where auto-zoom is applied for steady tracking and viewing. The subject’s dynamic location is continuously acquired and shared to another remote controller or to DJI FlightHub9.

    Aviation-Grade Situational Awareness

    The M300 RTK adopts a new Primary Flight Display (PFD) that integrates flight, navigation, and obstacle information to empower the pilot with exceptional situational awareness.

    A Powerful Vision System You Can Rely On

    To enhance in-flight safety and aircraft stability, dual-vision and ToF sensors appear on all six sides of the aircraft, offering a maximum detection range of up to 40 m, with options to customize the aircraft’s sensing behavior via the DJI Pilot App. Even in complex operating environments, this 6 Directional Sensing and Positioning system helps keep the aircraft and the mission safe.

    Professional Maintenance for Your Drone Fleet

    The new integrated Health Management System displays the current status of all systems, notification logs, and a preliminary troubleshooting guide. Also in the system are the aircraft’s flight logs, duration, and mileage throughout its entire lifecycle, and tips on aircraft care and maintenance.

    Redundancy Systems for Safer Flights

    The M300 RTK’s built-in advanced redundancy systems help keep your critical missions going even in unexpected scenarios.

    More Adaptable Than Ever Before

    IP45

    Self-Heating Battery

    -20°C to 50°C

    Anti-Collision Beacon

    AirSense ADS-B Receiver

    What's In the box?

    1 - DJI Matrice 300 RTK Aircraft
    1 - DJI Smart Controller Enterprise
    1 - USB Charger
    1 - USB-C Cable
    2 - TB60 Intelligent Flight Battery
    1 - WB37 Intelligent Flight Battery
    2 - Clockwise Propellers
    2 - Counter-Clockwise Propellers
    2 - Landing Gear
    1 - Spare Stick Cover (Pair)
    2 - Spare Propeller Holder 4 - Spare Gimbal Damper
    1 - USB Cable (with Double A Ports)
    1 - Vision System Calibration Plate
    1 - Carrying Case 1 - Smart Controller Lanyard
    1 - Rubber Port Cover (Set)
    1 - BS60 Intelligent Battery Station
    1 - Power Cable

    • 55 min Max Flight Time
    • 15km 1080p map transmission
    • 6 Directional Sensing and Positioning
    • -20°C to 50°C operating temperature

  • Specs

    Aircraft

    • Dimensions

    • Unfolded, propellers excluded, 810×670×430 mm (L×W×H)
      Folded, propellers included, 430×420×430 mm (L×W×H)

    • Diagonal Wheelbase

    • 895 mm

    • Weight (with single downward gimbal)

    • Approx. 3.6 kg (without batteries)
      Approx. 6.3 kg (with two TB60 batteries)

    • Single Gimbal Damper’s Max Payload

    • 930g

    • Max Takeoff Weight

    • 9 kg

    • Operating Frequency

    • 2.4000-2.4835 GHz
      5.725-5.850 GHz

    • EIRP

    • 2.4000-2.4835 GHz:
      29.5 dBm (FCC); 18.5dBm (CE)
      18.5 dBm (SRRC); 18.5dBm (MIC)

      5.725-5.850 GHz:
      28.5 dBm (FCC); 12.5dBm (CE)
      28.5 dBm (SRRC)

    • Hovering Accuracy (P-mode with GPS)

    • Vertical:
      ±0.1 m (Vision System enabled)
      ±0.5 m (GPS enabled)
      ±0.1 m (RTK enabled)

      Horizontal:
      ±0.3 m (Vision System enabled)
      ±1.5 m (GPS enabled)
      ±0.1 m (RTK enabled)

    • RTK Positioning Accuracy

    • When RTK enabled and fixed:
      1 cm+1 ppm (Horizontal)
      1.5 cm + 1 ppm (Vertical)

    • Max Angular Velocity

    • Pitch: 300°/s, Yaw: 100°/s

    • Max Pitch Angle

    • 30° (P-mode, Forward Vision System enabled: 25°)

    • Max Ascent Speed

    • S mode: 6 m/s
      P mode：5 m/s

    • Max Descent Speed (vertical)

    • S mode: 5 m/s
      P mode：4 m/s

    • Max Descent Speed (tilt)

    • S Mode: 7 m/s

    • Max Speed

    • S mode: 23 m/s
      P mode：17 m/s

    • Service Ceiling Above Sea Level

    • 5000 m (with 2110 propellers, takeoff weight ≤ 7 kg) / 7000 m (with 2195 propellers, takeoff weight ≤ 7 kg)

    • Max Wind Resistance

    • Max Wind Resistance 15 m/s (12 m/s when taking off or landing)

    • Max Flight Time

    • 55 min

    • Supported DJI Gimbals

    • Zenmuse XT2/XT S/Z30/H20/H20T/DJI P1/DJI L1

    • Supported Gimbal Configurations

    • Single Downward Gimbal, Dual Downward Gimbals, Single Upward Gimbal, Upward and Downward Gimbals, Triple Gimbals

    • Ingress Protection Rating

    • IP45

    • GNSS

    • GPS+GLONASS+BeiDou+Galileo

    • Operating Temperature

    • -20°C to 50°C (-4°F to 122° F)

    Remote Controller

    • Operating Frequency

    • 2.4000-2.4835 GHz
      5.725-5.850 GHz

    • Max Transmitting Distance (unobstructed, free of interference)

    • NCC/FCC: 15 km
      CE/MIC: 8 km
      SRRC: 8 km

    • EIRP

    • 2.4000-2.4835 GHz:
      29.5 dBm (FCC) 18.5dBm (CE)
      18.5 dBm (SRRC); 18.5dBm (MIC)

      5.725-5.850 GHz:
      28.5 dBm (FCC); 12.5dBm (CE)
      20.5 dBm (SRRC)

    • External battery

    • Name: WB37 Intelligent Battery
      Capacity: 4920 mAh
      Voltage: 7.6V
      Type: LiPo
      Energy: 37.39Wh
      Charging time (using BS60 Intelligent Battery Station): 70 minutes (15°C to 45°C); 130 minutes (0°C to 15°C)

    • Built-in battery

    • Type: 18650 lithium ion battery (5000 mAh @ 7.2 V)
      Charging: Use a USB charger with specification of 12V / 2A
      Rated power: 17 W
      Charging time: 2 hours and 15 minutes (Using a USB charger with specification of 12V / 2A)

    • Battery Life

    • Built-in battery: Approx. 2.5h
      Built-in battery+External battery: Approx. 4.5h

    • USB Power Supply

    • 5 V / 1.5 A

    • Operating Temperature

    • -20°C to 40°C (-4 °F to 104 °F)

    Vision System

    • Obstacle Sensing Range

    • Forward/Backward/Left/Right: 0.7-40m
      Upward/Downward: 0.6-30m

    • FOV

    • Forward/Backward/Downward: 65° (H), 50° (V)
      Left/Right/Upward: 75°(H), 60°(V)

    • Operating Environment

    • Surfaces with clear patterns and adequate lighting (> 15 lux)

    Infrared ToF Sensing System

    • Obstacle Sensing Range

    • 0.1-8m

    • FOV

    • 30° (±15°)

    • Operating Environment

    • Large, diffuse and reflective obstacles (reflectivity >10%)

    Top and bottom auxiliary light

    • Effective lighting distance

    • 5 m

    FPV Camera

    • Resolution

    • 960p

    • FOV

    • 145°

    • Frame rate

    • 30 fps

    Intelligent Flight Battery

    • Name

    • TB60

    • Capacity

    • 5935 mAh

    • Voltage

    • 52.8 V

    • Battery Type

    • LiPo 12S

    • Energy

    • 274 Wh

    • Net Weight

    • Approx. 1.35 kg

    • Operating Temperature

    • -4°F to 122°F (-20°C to 50°C)

    • Ideal storage temperature

    • 71.6°F to 86°F (22°C to 30°C)

    • Charging Temperature

    • -4°F to 104°F (-20°C to 40°C)
      (When the temperature is lower than 5°C, the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)

    • Charging time

    • Using BS60 Intelligent Battery Station:
      220V input: 60 minutes (fully charging two TB60 batteries), 30 minutes (charging two TB60 batteries from 20% to 90%)
      110V input: 70 minutes (fully charging two TB60 batteries), 40 minutes (charging two TB60 batteries from 20% to 90%)

    BS60 Intelligent Battery Station

    • Dimensions

    • 501*403*252mm

    • Net Weight

    • 8.37kg

    • Maximum Capacity

    • TB60 Intelligent Flight Battery × 8
      WB37 Intelligent Battery × 4

    • Input

    • 100-120 VAC, 50-60 Hz / 220-240 VAC, 50-60 Hz

    • Max. Input Power

    • 1070W

    • Output Power

    • 100-120 V: 750 W
      220-240 V: 992 W

    • Operating Temperature

    • -4°F to 104°F (-20°C to 40°C)

    Notes

    • The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

  • DJI Shield Basic 12 Months
